| Audio | Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC *
- Supports : Jack-detection, Multi-streaming, Front Panel
Jack-retasking, up to 24-Bit/192kHz playback,
Audio Feature :
- LED-illuminated design,
- Audio Shielding,
- Dedicated audio PCB layers,
- Premium Japanese audio capacitors |
| BIOS | 256 MB Flash ROM, UEFI AMI BIOS |
| Chipset | AMD B550 |
| CPU | AMD AM4 Socket for AMD Ryzen 5000 Series/ 4000 G-Series/ 3000
Series Desktop Processors |
| Form Factor | mATX Form Factor,
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
| HDMI | 1 x HDMI 2.1 (4K@60Hz) |
| Internal I/O Ports | Internal I/O Ports:
1 x CPU Fan connector(s),
2 x Chassis Fan connector(s),
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional
2 USB 3.2 Gen 1 port(s),
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),
1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage
devices support (SATA mode & X4 PCIE mode),
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (SATA mode & X4 PCIE mode),
4 x SATA 6Gb/s connector(s),
1 x S/PDIF out header(s),
1 x 24-pin EATX Power connector(s),
1 x 8-pin EATX 12V Power connectors,
1 x Front panel audio connector(s) (AAFP),
1 x Clear CMOS jumper(s),
1 x System panel connector,
1 x COM port header,
1 x Speaker connector,
Back I/O Ports:
1 x PS/2 keyboard/mouse combo port(s),
1 x DVI-D,
1 x D-Sub,
1 x HDMI,
1 x LAN (RJ45) port(s),
2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A),
4 x USB 3.2 Gen 1 (blue) Type-A,
3 x Audio jack(s) |
| LAN | Realtek RTL8111H 1GB Ethernet,
ASUS LANGuard |
| Memory | Type:
Dual Channel DDR4 Memory Technology,
Slots:
4 x DIMM,
Supported Memory:
AMD Ryzen 5000 Series/ 3000 Series Desktop Processors:
4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/
3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/
2666/2400/2133 MHz Un-buffered Memory,
AMD Ryzen 4000 G-Series Processors:
4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/
4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333
(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered
Memory,
Maximum Memory:
128GB, DDR4 |
| Storage | Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports,
AMD Ryzen 5000 Series/ 3000 Series Desktop Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/ 2280/ 22110
(PCIE 4.0 x4 and SATA modes) storage devices support,
AMD Ryzen 4000 G-Series Processors :
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE
3.0 x4 and SATA modes) storage devices support,
AMD B550 Chipset :
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4
and SATA modes) storage devices support,
4 x SATA 6Gb/s port(s),
Support Raid 0, 1, 10 |
| USB Port | Rear USB Port ( Total 6 ),
2 x USB 3.2 Gen 2 port(s)(2 x Type-A),
4 x USB 3.2 Gen 1 port(s)(4 x Type-A),
Front USB Port ( Total 6 ),
2 x USB 3.2 Gen 1 port(s)(2 x Type-A),
4 x USB 2.0 port(s)(4 x Type-A) |
