| BASIC INFORMATION | ||
| Form Factor | Micro-ATX Form Factor | |
| Basic Information | ||
| Chipset | Intel® B360 Chipset | |
| Audio | Realtek® ALC1220 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
|
| CPU | Supports 8th Generation Intel® Core™ Processors, and Intel® Pentium® Gold and Celeron® Processors for Socket LGA1151 |
|
| Memory | ||
| Memory | Type: Dual channel memory architecture Slots: 4 x DDR4 memory slots Supported Memory: Supports DDR4 2666/ 2400/ 2133 MHz Supports non-ECC UDIMM memory Supports Intel® Extreme Memory Profile (XMP) Maximum Memory: 64 GB |
|
| Graphics | ||
| Graphics | 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1 x DisplayPort, supports a maximum resolution of 4096X2304@60Hz 1 x HDMI™ port, supports a maximum resolution of 4096x2160@30Hz |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI™ port | |
| LAN | 1 x Intel I219-V Gigabit LAN controller | |
| Supported Storage | 4 x SATA 6Gb/s ports 2 x M.2 slots (Key M) M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices1 M2_2 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices**2 Intel® Optane™ Memory Ready ,supported on M2_2 3 SATA2 port will be unavailable when installing SATA M.2 SSD in M2_1 slot.M2_2 slot will be unavailable when installing a PCIe device in PCI_E4 slot.Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. |
|
| USB Port | 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-C and 1 Type-A ports on the back panel, 1 Type-C internal connector) 2 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connector 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector) |
|
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 03 years | |
