| BASIC INFORMATION | ||
| Chipset | INTEL B760 |
|
| Graphics | 1x HDMI Support HDMI 1.4 with HDR, maximum resolution of 4K 30Hz* 1x VGA |
|
| Memory | Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) Max. overclocking frequency: • 1DPC 1R Max speed up to 6400+ MHz • 1DPC 2R Max speed up to 5600+ MHz |
|
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
|
| Memory | ||
| Slots | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
|
| Connector & Ports | ||
| HDMI | Yes | |
| LAN | Realtek RTL8111H Gigabit LAN |
|
| Supported Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
|
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
|
| USB Port | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
|
| WARRANTY INFORMATION | ||
| Warranty | 3 Years |
|
At PC House, we're dedicated to giving our clients the greatest products at competitive costs. Because of this, we're pleased to provide the affordable MSI PRO B760M-E DDR5 M-ATx MOTHERBOARD. Furthermore, you can feel secure knowing that your investment is safeguarded thanks to the three-year warranty.
Here are some notable features of the MSI PRO B760M-E DDR5 M-ATX Motherboard:
If you need greater memory speeds and prefer Intel CPUs, the MSI PRO B760M-E DDR5 is generally superior because it supports DDR5 up to 6400+ MHz. For speedier storage, PCIe 4.0 is also available. On the other hand, the MSI A520M-A Pro AM4 is appropriate for more affordable setups as it supports AMD CPUs with DDR4 RAM. Your preference for RAM and CPU will determine your decision.
High-Performance Computing: Ideal for users needing powerful processing capabilities with support for Intel's latest CPUs and fast DDR5 memory.
Gaming: Provides strong performance for gaming due to its support for high-speed DDR5 memory and PCIe 4.0 storage, ensuring smooth gameplay and quick load times.
Content Creation: Suitable for video editing, 3D rendering, and other demanding content creation tasks, thanks to its high memory speeds and robust hardware support.
Future-Proof Builds: Great for building a system that stays relevant to the latest technology trends, offering faster memory and storage solutions.
With compatibility with the Intel B760 chipset and DDR5 memory running at speeds of up to 6400 MHz, the MSI PRO B760M-E DDR5 motherboard delivers strong performance. Data transmission rates are improved by its PCIe 4.0 slot and high-speed M.2 storage support. It is perfect for high-performance computing, gaming, and video creation because it has Realtek® ALC897 audio, HDMI, and VGA connections, and a wide range of connectivity options. All in all, it offers a comprehensive solution for high-end PC setups.
