| BASIC INFORMATION | ||
| Feature | Motherboard Support: E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX Enclosure Type: Mid-Tower Case Material: SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black) |
|
| General | Model: H5 Flow RGB 2024 Edition Model Number: CC-H52FB-R1 Type: Mid-Tower Color: Black |
|
| Case Features | ||
| Drive Bays | 2.5": 2 3.5": 1 |
|
| Expansion Slots | Standard: 7 Vertical: 0 |
|
| Fan Support | Front:3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included) Top:2 x 120 mm / 2 x 140 mm Bottom:2 x 120 mm br> Rear:1 x 120 mm (1 x F120Q Case Version included) |
|
| Inside the Box | H5 Flow RGB: 1 F360 RGB Core (CV): 1 F120Q (CV): 1 Installation accessories: 1 User guide: 1 |
|
| Radiator Support | Front: Up to 360 mm Top: Up to 240 mm (280mm with low-profile memory only) |
|
| Fan | Model: F360 RGB Core (Case Version) Speed: 1,700 ± 200 RPM Airflow: 50.1 CFM Static: 1.27 mm-H₂O Noise: 23.3 dBA Fan Connector: 3-pin Model:F120Q (Case Version) Speed:1,350 ± 150 RPM Airflow:60.2 CFM Static:1.05 mm-H₂O Noise:24.1 dBA Fan Connector:3-pin Fans Included 1x F360 RGB Core (CV) 1x F120Q (CV) |
|
| Key Features | ||
| Compatibility | CPU Cooler Height: Up to 170 mm GPU Length: Up to 410 mm PSU Length: Up to 200 mm Cable Management: Up to 28.7 mm Top Radiator: Up to 240 mm (280 mm with low-profile memory) Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness: Up to 55 mm |
|
| Connectivity | ||
| Front I/O Ports | USB 3.2 Type-A: 1 USB 3.2 Gen 2x2 Type-C (20 Gbps): 1 Headset Audio Jack: 1 |
|
| Physical Specifications | ||
| DIMENSIONS AND WEIGHT | Weight:7.63 kg / 16.82 lb Height (with feet):465 mm / 18.31 in Width:225 mm / 8.86 in Depth:430 mm / 16.93 in |
|
Enhanced Airflow and Cooling
One of the key highlights of the H5 Flow RGB is its superior airflow performance. The case features a full mesh front panel, providing an unobstructed path for fresh air to flow into the system, helping to keep your components cool even under heavy loads. This design is complemented by a top and bottom ventilation system that facilitates exhaust airflow, ensuring that heat doesn't build up inside the case. Whether you're running high-performance GPUs or an overclocked CPU, the H5 Flow RGB ensures that your system stays cool during intense gaming sessions or long rendering tasks.
RGB Lighting and Customization
The H5 Flow RGB 2024 Edition comes with pre-installed RGB fans (Aer RGB 2 fans), including one at the front and one at the rear. These fans offer vibrant, customizable RGB lighting that can be controlled via the included RGB controller, allowing you to sync lighting effects with other compatible components for a fully personalized aesthetic. The RGB fans not only add visual flair but also provide excellent airflow and quiet operation, ensuring both form and function are optimized.
Versatile Compatibility for Components
The H5 Flow RGB supports a wide range of components, making it highly versatile for different types of builds. It accommodates ATX, Micro-ATX, and Mini-ITX motherboards, and has enough room for graphics cards up to 340mm in length and CPU coolers up to 165mm in height. With this level of flexibility, you can easily install high-end gaming GPUs, powerful CPUs, and advanced cooling solutions, ensuring your system runs at peak performance.
Additionally, the case has ample storage options, with two 3.5" HDD bays and two 2.5" SSD trays, giving you plenty of room to expand your storage as needed.
Optimized for Cable Management
To help maintain a clean and organized interior, the H5 Flow RGB features a well-thought-out cable management system. It includes multiple routing channels, tie-down points, and an easy-to-remove cable cover, ensuring that cables are neatly organized and out of sight. This not only improves the visual appeal of your build but also helps optimize airflow by keeping cables from obstructing airflow paths.
Build Quality and Durability
Constructed with a solid steel frame and a premium finish, the H5 Flow RGB 2024 Edition is built to last. The white or black matte finish adds a modern, clean look to any setup, while the removable dust filters on the front, top, and bottom help to prevent dust buildup inside the case, ensuring that your components remain clean and perform optimally over time.
Connectivity and I/O Ports
For modern connectivity, the H5 Flow RGB comes equipped with a USB 3.1 Gen 2 Type-C port, which offers fast data transfer speeds, along with standard USB 3.0 and audio ports for easy access to your peripherals. The power/reset buttons are conveniently located on the top panel, making it easy to power up or shut down your system.
Conclusion
The NZXT H5 Flow RGB 2024 Edition is a high-performance, aesthetically pleasing PC case that combines superior airflow, customizable RGB lighting, and excellent component compatibility. It’s perfect for users who demand top-tier cooling performance, while also desiring a case that looks as good as it performs. Whether you’re building a powerful gaming rig, a content creation workstation, or simply want a visually stunning case with modern features, the H5 Flow RGB is a fantastic choice for your next build.
