| BASIC INFORMATION | ||
| Feature | Motherboard Support: E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
Enclosure Type: Mid-Tower Case Material: SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black) |
|
| General | Model: H5 Flow RGB 2024 Edition
Model Number: CC-H52FW-R1 Type: Mid-Tower Color: White |
|
| ANBERNIC | ||
| Box specification | H5 Flow RGB: 1 F360 RGB Core (CV): 1 F120Q (CV): 1 Installation accessories: 1 User guide: 1 | |
| Case Features | ||
| Drive Bays | 2.5": 2 3.5": 1 | |
| Expansion Slots | Standard: 7 Vertical: 0 | |
| Fan Support | Front:3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included) Top:2 x 120 mm / 2 x 140 mm Bottom:2 x 120 mm Rear:1 x 120 mm (1 x F120Q Case Version included) | |
| Radiator Support | Front: Up to 360 mm Top: Up to 240 mm (280mm with low-profile memory only) | |
| Fan | Model: F360 RGB Core (Case Version)
Speed: 1,700 ± 200 RPM
Airflow: 50.1 CFM
Static: 1.27 mm-H₂O
Noise: 23.3 dBA
Fan Connector: 3-pin
Model:F120Q (Case Version) Speed:1,350 ± 150 RPM Airflow:60.2 CFM Static:1.05 mm-H₂O Noise:24.1 dBA Fan Connector:3-pin Fans Included 1x F360 RGB Core (CV) 1x F120Q (CV) |
|
| Features | ||
| Compatibility | CPU Cooler Height: Up to 170 mm GPU Length: Up to 410 mm PSU Length: Up to 200 mm Cable Management: Up to 28.7 mm Top Radiator: Up to 240 mm (280 mm with low-profile memory) Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness: Up to 55 mm | |
| Physical Specifications | ||
| DIMENSIONS AND WEIGHT | Weight:7.63 kg / 16.82 lb Height (with feet):465 mm / 18.31 in Width:225 mm / 8.86 in Depth:430 mm / 16.93 in | |
One of the standout features of the H5 Flow RGB is its advanced airflow design. Unlike traditional cases that prioritize aesthetics over cooling, the H5 Flow is built for maximum air intake and exhaust, ensuring that your components stay cool during intense workloads or gaming sessions. The case features a full-mesh front panel that allows for unobstructed airflow, coupled with a high-performance top and bottom ventilation system. This ensures your system runs at optimal temperatures, even with high-end components. The H5 Flow RGB comes with two pre-installed Aer RGB 2 fans (one front and one rear) to provide stunning visual effects while promoting excellent airflow. These RGB fans can be controlled and customized through the included RGB controller, allowing you to synchronize lighting effects with other components for a fully personalized setup. The case supports additional fan mounts, including space for up to three 120mm fans or two 140mm fans in the front, as well as room for a 240mm radiator in the top or front, making it ideal for custom water cooling solutions.
Inside, the H5 Flow is spacious enough to support ATX, Micro-ATX, and Mini-ITX motherboards, as well as graphics cards up to 340mm in length and CPU coolers up to 165mm in height. The cable management system ensures that the interior remains tidy, with plenty of routing options and tie-down points for clean cable management. The case also features a USB 3.1 Type-C port, ensuring fast data transfer and modern connectivity, as well as additional USB and audio ports for convenience. The high-quality construction and aesthetic appeal make the NZXT H5 Flow RGB a great choice for anyone looking for a powerful, stylish, and airflow-optimized PC case.
In summary, the NZXT H5 Flow RGB 2024 Edition in White is a sleek, modern, and highly efficient case that not only showcases yo
