| Audio | - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec),
- Premium Blu-ray Audio support,
- Supports Surge Protection,
- ELNA Audio Caps,
- PCB Isolate Shielding,
- Individual PCB Layers for R/L Audio Channel |
| BIOS | - 256Mb AMI UEFI Legal BIOS with GUI support,
- Supports "Plug and Play",
- ACPI 5.1 compliance wake up events,
- Supports jumperfree,
- SMBIOS 2.3 support,
- CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, VDDG, CPU Load-Line Calibration, CPU VDDCR_SOC Load-Line Calibration Voltage Multi-adjustment |
| Chipset | AMD X570 |
| CPU | - AMD AM4 socket,
- Digi Power design,
- 10 Power Phase design |
| Form Factor | - ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm |
| Graphics | - Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU*,
- DirectX 12, Pixel Shader 5.0,
- Shared memory default 2GB. Max Shared memory supports up to 16GB.**,
- Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers,
- Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz,
- Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz,
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required),
- Supports HDR (High Dynamic Range) with HDMI 2.0,
- Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports,
- Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports,
- Supports Microsoft® PlayReady |
| HDMI | 1 x HDMI Port |
| Internal I/O Ports | - 3 x Antenna Ports (on I/O Panel Shield),
- 1 x PS/2 Mouse/Keyboard Port,
- 1 x HDMI Port,
- 1 x DisplayPort 1.2,
- 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection),
- 6 x USB 3.2 Gen1 Ports (Supports ESD Protection),
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED),
- HD Audio Jacks: Line in / Front Speaker / Microphone |
| LAN | - Gigabit LAN 10/100/1000 Mb/s,
- Giga PHY Intel® I211AT,
- Supports Wake-On-LAN,
- Supports Lightning/ESD Protection,
- Supports Energy Efficient Ethernet 802.3az,
- Supports PXE |
| Memory | Type:
Dual Channel DDR4 Memory Technology,
Slots:
4 x DDR4 DIMM Slots,
Supported Memory:
- AMD Ryzen series CPUs (Matisse) support DDR4 4066+(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory,
- AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 ECC & non-ECC, un-buffered memory,
- AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory,
Maximum Memory:
128GB |
| Storage | AMD Ryzen series CPUs (Matisse),
- 2 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3)),
AMD Ryzen series CPUs (Pinnacle Ridge),
- 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3)),
AMD Ryzen series CPUs (Picasso),
- 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x8 (PCIE1); dual at x8 (PCIE1) / x4 (PCIE3)),- 2 x PCI Express 4.0 x1 Slots,
- Supports AMD Quad CrossFireX and CrossFireX,
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module,
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
| USB Port | - 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection),
- 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) |
