| BASIC INFORMATION | ||
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information | |
| Form Factor | Extended ATX Form Factor 12 inch x 10.6 inch ( 30.5 cm x 26.9 cm ) | |
| Basic Information | ||
| Chipset | AMD X399 | |
| Audio | 5 x Audio jack(s) | |
| CPU | AMD Socket TR4 for AMD Ryzen™ Threadripper™ Processors | |
| Memory | ||
| Slots | AMD Ryzen™ Threadripper™ Processors || 4 x PCIe 3.0 x16 (single@x16, dual@x16/x16, triple@x16/x16/x8 mode) || AMD X399 chipset || 1 x PCIe 2.0 x4 (max at x4 mode) || 1 x PCIe 2.0 x1 | |
| Memory | AMD Ryzen™ Threadripper™ Processors || 8 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory | |
| Storage | AMD Ryzen™ Threadripper™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) || 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) || 1 x U.2 port || AMD X399 chipset : 6 x SATA 6Gb/s port(s), || Support Raid 0, 1, 10 | |
| Connector & Ports | ||
| LAN | Intel® I211-AT || ASUS Turbo LAN Utility || ASUS LAN Guard | |
| Internal I/O Ports | 1 x LAN (RJ45) port(s)|| 2 x USB 3.1 Gen 2 (teal blue)Type-A + USB Type-CTM || 8 x USB 3.1 Gen 1 (blue) ||1 x Optical S/PDIF out || 5 x Audio jack(s) || 1 x USB BIOS Flashback Button(s) | |
| USB Port | AMD Ryzen™ Threadripper™ Processors : 8 x USB 3.1 Gen 1 port(s) (8 at back panel, , Type-A) || AMD X399 chipset : 1 x USB 3.1 Gen 2 port(s) (1 at mid-board) || AMD X399 chipset : 4 x USB 3.1 Gen 1 port(s) (4 at mid-board) || AMD X399 chipset : 4 x USB 2.0 port(s) (4 at mid-board)|| ASMedia® USB 3.1 Gen 2 controller : 2 x USB 3.1 Gen 2 port(s) (Type-A + USB Type-CTM) || | |
| WARRANTY INFORMATION | ||
| Warranty | 3 years warranty available | |
Ready for 1st and 2nd Gen AMD Ryzen™ Threadripper™ series processors.5-Way Optimization: One-click, system-wide tuning, delivering optimized overclocks and intelligent cooling for CPU or GPU-intensive tasks.Industry-leading cooling options: Comprehensive controls for fans and water pumps, via Fan Xpert 4 software or the acclaimed ASUS UEFI.Next-gen connectivity: Onboard U.2, M.2 and front-panel USB 3.1 Gen 2 connector.M.2 heatsink: Ultra-efficient heatsink reduces M.2 SSD temperatures by up to 20°C for unthrottled transfer speeds and enhanced reliability.Aura Sync: Controllable onboard RGB lighting easily syncs with an ever-growing portfolio of Aura Sync-capable hardware.
