| BASIC INFORMATION | ||
| Supported CPU | AMD AM4 Socket For AMD Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors | |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | Mini ITX Form Factor | |
| Basic Information | ||
| Chipset | B550 Chipset | |
| Audio | SupremeFX7.1 Surround Sound High Definition Audio CODEC S1220A - Rear Audio USB Type-C® Port - LED-Illuminated Design - Audio Shielding - Premium Japanese Audio Capacitors - Dual OP Amplifiers - Impedance Sense For Front And Rear Headphone Outputs - Supports : Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking - High Quality120dBSNR Stereo Playback Outputand113dBSNR Recording Input - Supports Up To 32-Bit/192kHz Playback | |
| Memory | ||
| Slots | AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors 1 X PCIe 4.0 X16 (X16 Mode) 1 X PCIe 3.0 X16 (X16 Mode | |
| Memory | AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors 2 X DIMM, Max. 64GB, DDR4 5100(O.C)/5000(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3800(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-Buffered Memory * OptiMem II Dual Channel Memory Architecture ECC Memory (ECC Mode) Support Varies By CPU. | |
| Graphics | ||
| Graphics | 1 X HDMI 2.1(4K@60HZ) 1 X DisplayPort 1.4 | |
| Connector & Ports | ||
| LAN | Intel I225-V 2.5Gb Ethernet ASUS LANGuard | |
| Supported Storage | AMD RyzenTM 4000 G-Series Processors : AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors : Total Supports 2 X M.2 Slot(S) And 4 X SATA 6Gb/S Ports AMD B550 Chipset : 1 X M.2_2 Socket 3, With M Key, Type 2242/2260/2280 (PCIE 4.0 X4 And SATA Modes) Storage Devices Support 1 X M.2_1 Socket 3, With M Key, Type 2242/2260/2280 (PCIE 4.0 X4 And SATA Modes) Storage Devices Support 4 X SATA 6Gb/S Port(S), Support Raid 0, 1, 10 1 X M.2_1 Socket 3, With M Key, Type 2242/2260/2280 (PCIE 3.0 X4 And SATA Modes) Storage Devices Support | |
| Internal I/O Ports | 1 X USB 3.2 Gen2 Connector Support Additional 1 USB Ports(20-Pin, Type-C) 1 X VRM_HS_FAN Header 1 X USB 3.2 Gen 1(Up To 5Gbps) Connector(S) Support(S) Additional 2 USB 3.2 Gen 1 Port(S) 2 X M.2 Socket 3 With M Key Design, Type 2242/2260/2280 Storage Devices Support (Supports Both SATA & PCIE SSD) 1 X CPU Fan Connector(S) 1 X Chassis Fan Connector(S) 1 X AIO_PUMP Connector 1 X Aura RGB Strip Header(S) 1 X Addressable Gen 2 Header(S) 1 X USB 2.0 Connector(S) Support(S) Additional 2 USB 2.0 Port(S) 4 X SATA 6Gb/S Connector(S) 1 X 24-Pin EATX Power Connector(S) 1 X 8-Pin ATX 12V Power Connector(S) 1 X Front Panel Audio Connector(S) (AAFP) 1 X Thermal Sensor Connector(S) 1 X Clear CMOS Jumper(S) 1 X System Panel Connector 1 X Speaker Connector | |
| USB Port | 4 X USB 3.2 Gen 2 Port(S)(1 X USB Type-C® +3 X Type-A) 1 X USB 2.0 Port(S)(1 X Audio USB Type-C® ) Front USB Port ( Total 5 ) 1 X USB 3.2 Gen 2 Front Panel Connector Port(S)(1 X USB Type-C®) Rear USB Port ( Total 6 ) 1 X USB 2.0 Port(S) 2 X USB 3.2 Gen 1 Port(S) 2 X USB 2.0 Port(S) | |
| WiFi | 2x2 Wi-Fi 6 (802.11 A/B/G/N/Ac/Ax) Support 1024QAM/OFDMA/MU-MIMO Intel® Wi-Fi 6 AX200 Supports Dual Band Frequency 2.4/5 GHz Supports Channel Bandwidth: HT20/HT40/HT80/HT160 | |
| WARRANTY INFORMATION | ||
| Warranty | 3 Year | |
ROG Strix B550 Gaming Series Motherboards Offer A Feature-Set Usually Found Within The Higher-End ROG Strix X570 Gaming Series, Including The Newest PCIe 4.0. With Robust Power Delivery And Effective Cooling, ROG Strix B550 Gaming Is Well-Equipped To Handle 3rd Gen AMD Ryzen CPUs. Boasting Futuristic Aesthetics And Intuitive ROG Software, ROG Strix B550-I Gaming Is Prepared To Become Your Next Compact Gaming Build.
AMD AM4 Socket
ASUS ROG STRIX B550-I Motherboard Ready For Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
Connectivity
ASUS ROG STRIX B550-I Motherboard Has PCIe 4.0-Ready, Dual M.2, USB 3.2 Gen 2 Type-C Plus HDMI 2.1 And DisplayPort 1.4 Output
Smooth Networking
ASUS ROG STRIX B550-I Motherboard Onboard WiFi 6 (802.11ax) And Intel 2.5 Gb Ethernet With ASUS LANGuard
Robust Power Solution
ASUS ROG STRIX B550-I Motherboard Teamed Power Stages With ProCool II Power Connector, High-Quality Alloy Chokes, And Sturdy Capacitors
Renowned Software
Intuitive Dashboards For UEFI BIOS And ASUS AI Networking Make ASUS ROG STRIX B550-I Motherboard Easy To Configure Gaming Builds
Unmatched Personalization
ASUS-Exclusive Aura Sync RGB Lighting, Including Aura RGB Header And Addressable Gen 2 RGB Header
Gaming Audio
Audio USB Type-C, AI Noise Canceling Microphone, ASUS ROG STRIX B550-I Motherboard SupremeFX S1220A Codec, DTS Sound Unbound, And Sonic Studio III For Immersive Audio
