| Audio | Realtek ALC887 8-Channel High Definition Audio CODEC,
- Supports : Jack-detection, Front Panel Jack-retasking,
Audio Feature :
- Audio Shielding: Ensures precision analog/digital separation and
greatly reduced multi-lateral interference,
- Dedicated audio PCB layers: Separate layers for left and right
channels to guard the quality of the sensitive audio signals,
- Premium Japanese audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and fidelity |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1,
Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3,
F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites,
Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD
(Serial Presence Detect) memory information |
| Chipset | AMD A320 |
| CPU | AMD AM4 Socket for 3rd/2nd/1st Gen AMD Ryzen/2nd and 1st Gen
AMD Ryzen with Radeon Vega Graphics/Athlon with Radeon
Vega Graphics/7th Generation A-series/Athlon X4 Processors
Supports CPU up to 8 cores |
| Form Factor | 6.7 inch x 6.7 inch ( 17 cm x 17 cm ) |
| Graphics | Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega
Graphics/ Athlon with Radeon Vega Graphics/ 7th Generation A-Series APU,
Multi-VGA output support : HDMI/DisplayPort ports,
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz,
- Supports DisplayPort with max. resolution 4096 x 2160 @ 60 Hz |
| HDMI | 1 x HDMI 1.4b (max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz) |
| Internal I/O Ports | 1 x CPU Fan connector(s),
1 x CPU OPT Fan connector(s) (1 x 4 -pin),
2 x Chassis Fan connector(s) (1 x 4 -pin),
2 x Aura RGB Strip Headers,
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional
2 USB 3.2 Gen 1 port(s) (19-pin),
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s),
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (SATA & PCIE 3.0 x 4 mode),
4 x SATA 6Gb/s connector(s),
1 x 24-pin EATX Power connector(s),
1 x 8-pin ATX 12V Power connector(s),
1 x Front panel audio connector(s) (AAFP),
1 x System panel(s),
1 x Clear CMOS jumper(s) |
| LAN | Realtek RTL8111H, 1 x Gigabit LAN Controller(s),
ASUS LAN Guard |
| Memory | Type:
Dual Channel DDR4 Memory Technology,
Slots:
2 x DIMM,
Supported Memory:
3rd and 2nd Gen AMD Ryzen Processors:
3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3200(O.C.)/ 3000(O.C.)/
2933(O.C.)/ 2800(O.C.)/ 2666/ 2400/ 2133 MHz Non-ECC,
Un-buffered Memory,
AMD Ryzen with Radeon Vega Graphics/ Ryzen 1st Generation
Processors,
3400(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2933(O.C.)/ 2800(O.C.)/ 2666/
2400/ 2133 MHz Non-ECC, Un-buffered Memory,
AMD 7th Generation A-series/Athlon Processors,
2400/ 2133 MHz Non-ECC, Un-buffered Memory,
Maximum Memory:
64 GB |
| Storage | 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with
Radeon Vega Graphics :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage
devices support (SATA & PCIE 3.0 x 4 mode),
AMD 7th Generation A-Series/ Athlon X4 Processors :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage
devices support (SATA mode),
AMD Athlon with Radeon Vega Graphics Processors :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage
devices support (SATA mode),
AMD A320 chipset :
4 x SATA 6Gb/s port(s), gray,
Support Raid 0, 1, 10 |
| USB Port | 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with
Radeon Vega Graphics/ Athlon with Radeon Vega Graphics/
7th Generation A-series/ Athlon X4 Processors :
4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue),
AMD A320 chipset :
2 x USB 3.0 port(s) (2 at mid-board),
AMD A320 chipset :
4 x USB 2.0 port(s) (2 at back panel, black, 2 at mid-board) |
