| Motherboard | |
| Audio | - 7.1 CH HD Audio (Realtek ALC887 Audio Codec), - Supports Surge Protection, - ELNA Audio Caps |
| BIOS | - 128Mb AMI UEFI Legal BIOS with GUI support, - SMBIOS 2.3 support |
| Chipset | - AMD Promontory B450 |
| CPU | - AMD AM4 Socket, - Digi Power design, - Supports CPU up to 105W |
| Form Factor | - Micro ATX Form Factor: 9.1-in x 8.1-in, 23.1 cm x 20.6 cm |
| Graphics | Max Shared Memory: - Max Shared memory supports up to 16GB, - The Max shared memory 16GB requires 32GB system memory installed. |
| HDMI | - 1 x HDMI Port |
| Internal I/O Ports | - 1 x PS/2 Mouse/Keyboard Port, - 1 x D-Sub Port, - 1 x DVI-D Port, - 1 x HDMI Port, - 2 x USB 2.0 Ports (Supports ESD Protection), - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection), - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), - HD Audio Jacks: Line in / Front Speaker / Microphone, - 1 x COM Port Header, - 1 x Chassis Intrusion and Speaker Header, - 1 x CPU Fan Connector (4-pin)*, - 2 x Chassis Fan Connectors (1 x 3-pin, 1 x 4-pin)**, - 1 x 24 pin ATX Power Connector, - 1 x 4 pin 12V Power Connector, - 1 x Front Panel Audio Connector, - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection), - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) |
| LAN | - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
| Memory | Type: - Dual Channel DDR4 Memory Technology, Slots: - 2 x DDR4 DIMM Slots, - 15μ Gold Contact in DIMM Slots, Supported Memory: For Ryzen Series CPUs (Raven Ridge), ECC is only supported with PRO CPUs. |
| USB Port | - 6 USB 3.1 Gen1 (2 Front, 4 Rear), - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection), - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection), - 2 x USB 2.0 Ports (Supports ESD Protection), - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection) |
| WARRANTY INFORMATION | |
| Manufacturing Warranty | 03 Years warranty |
ASRock A320M-HDV R4.0 AMD Motherboard built in AMD AM4 Socket with AMD Promontory B450 chipset.This Motherboard supports SATA3 6Gb/s M.2 modules, and is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen3 x4 SSDs.
The main component of the Motherboard
This Motherboard Supports CPU up to 105W with Vega Series Graphics in Ryzen Series APU.It has Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables, 1 x Screw for M.2 Socket.For graphical support ,It has DirectX 12, Pixel Shader 5.0, Three graphics output options: D-Sub, DVI-D and HDMI. That Motherboard can supports triple Monitor, HDMI with max. resolution up to 4K x 2K (4096×2160) @ 24Hz / (3840×2160) @ 30Hz, DVI-D with max. resolution up to 1920×1200 @ 60Hz, D-Sub with max. resolution up to 2048×1536 @ 60Hz, Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required), HDCP 1.4 with DVI-D and HDMI Ports and 4K Ultra HD (UHD) playback with HDMI Port.
In this amazing ASRock A320M-HDV R4.0 AMD Motherboard the ASRock APP Charger, ASRock XFast LAN is used. Moreover, In this exclusive Motherboard used in different types of memory storage ; these are – Dual Channel DDR4 Memory Technology, 2 x DDR4 DIMM Slots, AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3200+(OC) / 2933(OC) / 2667/2400/2133 ECC & non-ECC, un-buffered memory, AMD Ryzen series CPUs (Raven Ridge) support DDR4 3200+(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory, AMD 7th Gen A-Series APUs support DDR4 2400/2133 non-ECC, un-buffered memory, Max. capacity of system memory is 32GB, 15μ Gold Contact in DIMM Slot. In this Motherboard, 128Mb AMI UEFI Legal BIOS with GUI support, Plug and Play”, ACPI 5.1 compliance wake up events, jumperfree, SMBIOS 2.3 support, DRAM Voltage multi-adjustment are support. They have include PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111H and Supports Wake-On-LAN, Lightning/ESD Protection, Energy Efficient Ethernet 802.3az and PXE in this exclusive grapics card.
Special Features of this Motherboard That must be considered
Have a look on the special features of this board that might firm your buying decision.This ASRock A320M-HDV R4.0 AMD Motherboard supports PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. In addition, it also supports SATA3 6Gb/s M.2 modules, and is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen3 x4 SSDs.PCB appearance represents rock-solid quality and gives the motherboard a more mysterious touch. In this Motherboard High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the Motherboard against electrical shorts caused by humidity and also the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.You can easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.For gaming or entertainment these are the features one should consider of purchasing it.
The ASRock B450M-HDV R4.0 AMD Motherboard is Out Of Stock now. You can buy the ASRock B450M-HDV R4.0 AMD Motherboard at the best price from our website or visit any of our showrooms When the product available.
