| Graphics Card | ||
| Type | GDDR7 | |
| Size | 16GB | |
| Resolution | Up to 4K 480Hz or 8K 165Hz with DSC | |
| Core Clock | 2512 MHz |
|
| Memory Clock | 28 Gbps | |
| BUS Type | 256-bit |
|
| Memory Interface | PCI Express 5.0 x16 | |
| CUDA Cores | 8960 |
|
| Display Port | 3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) |
|
| HDMI | 1 x HDMI Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification) |
|
| HDCP Support | 2.3 | |
| Connectors | 1 x 12v-2x6 power input | |
| Recommended PSU | 750W |
|
| Consumption | 300W *High power consumption, please carefully read your PSU manual before installation. | |
| Multi Display | Quad Display | |
| DirectX Support | Microsoft DirectX 12 Ultimate | |
| OpenGL | 4.6 | |
| Dimensions | 332.1mm x 137.5mm x 69.6mm / 13.1" x 5.4" x 2.7" | |
| Others | Powered by the NVIDIA Blackwell architecture and DLSS 4 Strongest factory OC The ultimate ZOTAC GAMING GPU Infinity Mirror Design IceStorm 3.0 Advanced Cooling Larger Vapor Chamber BladeLink Fans FREEZE Fan Stop, Active Fan Control, Dual BIOS SPECTRA 2.0 RGB Lighting SPECTRA LINK Lighting Sync port Metal die-cast Backplate Bundled with GPU Support Bracket 12V-2x6 Safety Light |
|
| Warranty | 3 Years | |
The ZOTAC GAMING GeForce RTX 5070 Ti AMP Extreme INFINITY ULTRA is the crown jewel of ZOTAC’s 50-series lineup, engineered for enthusiasts who demand flagship-level cooling and aesthetics on a mid-to-high-end GPU. Built on the NVIDIA Blackwell architecture, this "ULTRA" variant features the most aggressive factory overclock in its class.Flagship Performance & MemoryThe inclusion of 16GB of next-gen memory ensures this card remains relevant for high-fidelity 4K gaming and complex AI workloads for years to come:CUDA Cores: 8,960Engine Boost Clock: Factory overclocked to a blistering 2572 MHz.Memory: 16GB GDDR7 on a 256-bit bus.Bandwidth: A massive 896 GB/s (28 Gbps effective speed), a 77% increase over the previous generation.AI Power: Equipped with 5th Gen Tensor Cores, it delivers elite DLSS 4 performance with Multi Frame Generation.The "Infinity" Aesthetic & CoolingThe card features ZOTAC’s new Infinity Mirror design, creating a deep, holographic RGB effect on the shroud that is customizable via SPECTRA 2.0.IceStorm 3.0 Cooling: This massive 3.5-slot card utilizes a vapor chamber that is 34% larger than standard models, paired with triple 100mm BladeLink fans.Dual BIOS: A physical switch allows users to choose between Quiet and Performance profiles.SPECTRA LINK: A dedicated header allows you to sync your external LED strips or case lighting directly with the GPU’s lighting effects.Physicality & PowerGiven its size ($332.1 \times 137.5 \times 69.6\text{ mm}$), the card comes bundled with a ZOTAC GAMING GPU Support Stand to prevent motherboard stress. It has a 300W TDP, requiring a 750W PSU and a single 12V-2x6 power connector. Connectivity is top-tier with 3x DisplayPort 2.1b and 1x HDMI 2.1b, supporting up to 8K at 165Hz.
