| Audio | SupremeFX 8-Channel High Definition Audio CODEC S1220A
- Dual OP Amplifiers,
- Impedance sense for front and rear headphone outputs,
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking,
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input,
- SupremeFX Shielding Technology,
- Supports up to 32-Bit/192kHz playback *3,
Audio Feature :
- Optical S/PDIF out port(s) at back panel,
- Sonic Radar III,
- Sonic Studio III + Sonic Studio Link |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,
ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log,
F12 PrintScreen, Secure Erase, User Profile, F4 AURA ON/OFF, F9 Search, and ASUS DRAM SPD (Serial Presence Detect) memory information. |
| Chipset | AMD X470 |
| CPU | AMD AM4 Socket AMD Ryzen™ 2nd Generation/Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation/7th Generation A-series/Athlon X4 Processors
Supports CPU up to 8 cores |
| Form Factor | ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| Graphics | Graphics:
Multi-VGA output support : HDMI/DisplayPort ports,
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz,
- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz,
Max Shared Memory:
2048 MB |
| HDMI | 1 x HDMI Port |
| Internal I/O Ports | 1 x Aura Addressable Strip Header(s),
2 x Aura RGB Strip Header(s),
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode),
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode),
1 x TPM connector(s),
6 x SATA 6Gb/s connector(s),
1 x CPU Fan connector(s),
1 x CPU OPT Fan connector(s),
3 x Chassis Fan connector(s),
1 x AIO_PUMP connector,
1 x W_PUMP+ connector,
1 x 24-pin EATX Power connector(s),
1 x 8-pin ATX 12V Power connector(s),
1 x Front panel audio connector(s) (AAFP),
1 x Thermal sensor connector(s),
1 x Clear CMOS jumper(s),
1 x System panel connector,
1 x COM port header,
1 x USB 3.1 Gen 2 front panel connector,
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) |
| LAN | Intel® I211-AT, 1 x Gigabit LAN Controller(s),
Anti-surge LANGuard,
ROG GameFirst Technology |
| Memory | Type:
Dual Channel DDR4 Memory Technology,
Slots:
4 x DDR4 DIMM,
Supported Memory:
AMD Ryzen™ 2nd Generation Processors,
DDR4 ,3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory *,
Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors,
DDR4 3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory *,
AMD 7th Generation A-Series/Athlon X4 Processors,
DDR4 2400/2133 MHz Un-buffered Memory,
Maximum Memory:
64 GB |
| Storage | AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors :
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode),
AMD 7th Generation A-series/Athlon™ Processors :
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode),
AMD X470 chipset :
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)*2
6 x SATA 6Gb/s port(s),
AMD Athlon™ with Radeon™ Vega Graphics Processors :
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode),
Support Raid 0, 1, 10 |
| USB Port | AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/ 7th Generation A-Series/ Athlon™ X4 Processors :
4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue),
AMD X470 chipset :
1 x USB 3.1 Gen 2 front panel connector port(s),
AMD X470 chipset :
4 x USB 3.1 Gen 1 port(s) (2 at back panel, , 2 at mid-board),
AMD X470 chipset :
4 x USB 2.0 port(s) (4 at mid-board),
ASMedia® USB 3.1 Gen 2 controller :
2 x USB 3.1 Gen 2 port(s) (2 at back panel, red, Type-A) |
