MAXLINK XPON ONU ML-X801HQ

Name: MAXLINK XPON ONU ML-X801HQ
Brand: Generic
SKU: 13027
Price: 1050 BDT
Availability: InStock
Rating: 5 (2 reviews)

Price: 990৳ ~~1,050৳~~

Status: In Stock

Product Code: 13027

Payment Options

990৳ ~~1,050৳~~

Cash Discount Price

Online / Cash Payment

165৳/month

Regular Price: 990৳

EMI Facility Available***

Quantity :

Chat Through

Whatsapp Messenger 09617179141

Specification
Description
Reviews ( 0)

Specification:

BASIC INFORMATION
Feature	Dual mode(Can access EPON/GPON OLTs) Compatible with popular OLT(s) Industrial Design Routing or Bridging Mode Detecting Rogue ONU Flow & Storm Control , Loop Detection Firewall: DDOS, Filtering Based on ACL/MAC/URL O&M: WEB/TELNET/OAM(OMCI)/TR069
Material	Plastic casing
Features
Dimension	(L x W x H): 110 x100 x 23mm
Interface	Downstream Data Rate: 2.488Gbps Upstream Data Rate: 1.244Gbps SC/UPC single-mode fiber PON Port: 1 x XPON port, FSAN G.984.2 standard/IEEE802.3ah: 28dB Link loss and 20KM distance with 1:128: Receiving sensitivity: ≤-30dBm: Transmitting optical power: 0~+4dBm
Others	Ethernet Port (LAN): 1 x GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45, Auto-MDI/MDI-X Transmission Distance: 100 Meters Environment: Operating Temperature: 0～50℃ Storage Temperature: -40～85℃ Operating Humidity: 10～90% (Non-condensing) Storage Humidity: 10～90% (Non-condensing)
Weight	300gm
Connectivity
Power	Power Supply: 12V, 0.5A DC input Power Consumption: up to 3W

Description :

MAXLINK XPON ONU ML-X801HQ

This MAXLINK XPON ONU ML-X801HQ is designed to meet the requirements of broadband access networks. It features high-performance forwarding capabilities that will ensure an excellent experience with HD video services. This ONT will support a seamless terminal solution and future-oriented services for FTTH implementation. It is well-compatible with third-party OLTs including Huawei, ZTE, and Fiber Home.

Interface

Downstream Data Rate: 2.488Gbps

Upstream Data Rate: 1.244Gbps

SC/UPC single-mode fiber

PON Port

1 x XPON port, FSAN G.984.2 standard/IEEE802.3ah

28dB Link loss and 20KM distance with 1:128

Receiving sensitivity: ≤-30dBm

Transmitting optical power: 0~+4dBm

Ethernet Port (LAN)

1 x GE Auto-negotiation RJ45 ports

Full Duplex / Half-Duplex

RJ45, Auto-MDI/MDI-X

Transmission Distance: 100 Meters

Power

Power Supply: 12V, 0.5A DC input

Power Consumption: up to 3W

Environment

Operating Temperature: 0～50℃

Storage Temperature: -40～85℃

Operating Humidity: 10～90% (Non-condensing)

Storage Humidity: 10～90% (Non-condensing)

Shell: Plastic casing

Dimension(L x W x H): 110 x100 x 23mm

Weight: 300gm
