| General | ||
| Dimension | Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod) Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod) |
|
| Weight | Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws) Grip: Approx. 274 g (0.6 lbs) Quick-Open Tripod: Approx. 149 g (0.3 lbs) Upper and Lower Quick-Release Plates: Approx. 96 g (0.21 lbs) (including screws) |
|
| Compatibility | iOS 14.0 or above Android 9.0 or above |
|
| Battery | ||
| Type | LiPo 4S | |
| Capacity | 2150 mAh | |
| Energy | 33.29 Wh | |
| Charging Temperature | Suggested: 5° to 40° C (41° to 104° F) | |
| Operating Temperature | Approx. 3.5 hours | |
| Operating Time | Approx: 1 hour | |
| Ports | Charging Port (USB-C) | |
| Mount | Mounting Method: Magnetic attachment | |
| Voltage | 11.2 V to 17.8 V | |
| Gimbal | ||
| Mechanical Range | Pan Axis: 360° continuous rotation Roll Axis: -95° to +240° Tilt Axis: -112° to +214° |
|
| Max Controllable Speed | Pan: 360°/s Tilt: 360°/s Roll: 360°/s |
|
| Wireless | Bluetooth 5.0 | |
| Maximum Load | 3 kg (6.6 lbs) | |
| Camera | ||
| Warranty | ||
| Warranty | 1 Year DJI Warranty. (Warranty will be void if the product has been physically damaged) | |
The DJI RS 4 is a professional-grade 3-axis stabilizer designed to serve as the backbone for serious mirrorless camera cinematography. Building on the success of its predecessors, this model focuses on efficiency, capacity, and the rising demand for vertical filmmaking, making it a versatile tool for wedding videographers and indie filmmakers alike.
The RS 4 features the 4th-Gen RS Stabilization Algorithm, specifically optimized for various shooting scenarios, including running or low-angle tracking. It maintains a robust 3kg (6.6 lbs) payload capacity, easily supporting common setups like the Sony A7S III or Canon R5 with a 24-70mm f/2.8 lens. A significant physical upgrade is the Teflon™ coating on all three axes, which reduces friction and makes the balancing process significantly smoother and more precise.
One of the most praised features is the 2nd-Gen Automated Axis Locks. When the gimbal is powered off, the axes fold and lock automatically; when powered on, they expand and unlock in seconds, allowing creators to start filming almost instantly. For social media creators, the 2nd-Gen Native Vertical Shooting allows for a seamless transition to 9:16 framing by simply re-mounting the horizontal plate—no additional accessories or rebalancing required.
The handle features a 1.4-inch OLED touchscreen with a new auto-lock function to prevent accidental touches. Key performance features include:
Dual-Mode Bluetooth: Control shutter and zoom wirelessly on supported cameras.
Joystick Mode Switch: Quickly toggle the joystick between controlling gimbal movement or power zoom.
RSA Communication Port: Allows for extensive customization with accessories like the DJI RS Briefcase Handle or third-party control systems.
The RS 4 provides up to 12 hours of battery life. For high-intensity production days, it is compatible with the RS BG70 High-Capacity Battery Grip, which can extend the total runtime to a staggering 29.5 hours.
