BenQ RP7502 Interactive Whiteboard Specification
Panel
| - Screen Size: 75''
- Panel Type: IPS
- Resolution: UHD 3840 × 2160 Pixels
- Active Area: 1649.7 × 927.9 Mm
- Aspect Ratio: 16:9
- Brightness (Typical): 450 Nits
- Contrast Ratio (Typical): 1200:1
- Dynamic Contrast Ratio: 30,000:1
- Color Depth: 10-Bit
- Response Time: 8 Ms
- Color Gamut: 72% NTSC
- Operation Hours: 18 Hours / 7 Days
- Orientation: Landscape
- Light Life (Typical): 50,000 Hrs
|
Glass
| - Hardness: 9H Tempered
- Germ-Resistant Technology: Nano-Ionic Silver
- Anti-Glare Coating: Yes
|
Touch Screen
| - Touch Technology: Infrared Touch
- Touch Points: 20
- Touch Response Time: < 4 Ms
|
System
| - CPU: A73 × 2 + A53 × 2
- GPU: Mali-G51MP4
- Memory | Storage: 4GB I 32GB
- OS: Android 8.0
|
Connectivity
| - HDMI (In | Out): 3 × HDMI 2.0 | 1 ×
- HDMI 2.0
- VGA (In | Out): 1 | 0
- 3.5 Mm Audio In (VGA): 1
- 3.5 Mm Audio (In | Out): Mic-In | Line-Out
- USB-A: 3 × 2.0 + 2 × 3.2 Gen1
- USB-B (For Touch): 3 × 2.0
- USB-C: 1 × 3.1
- Slot-In PC (OPS): 1
- Ethernet LAN: 10 / 100 Mbps (Android)
|
Built-In Peripherals
| - Microphone: 8
- Speaker: 2 × 16 W
- Subwoofer: 1 × 15 W
- Ambient Light Sensor: Yes
- Temperature Sensor: 1
- Humidity Sensor: 1
- Air Sensor: TVOC
- Motion Sensor: 3
- NFC: Yes
|
Power
| - Power: AC 100-240V 50/60Hz
- Maximum Power Consumption:375 W
- Standby Power Consumption: <0.5 W
- Typical Power Consumption: 262 W
|
Physical
| - Dimensions (W X H X D): 1735.5 × 1085.8 × 130.7 Mm (68.3 × 42.7 × 5.2 Inch)
Shipping Dimensions (W X H X D): 1900 × 1160 × 225 Mm (74.8 × 45.7 × 8.9 Inch) Weight (Product I Shipping): 61 Kg | 78 Kg (134.5 Lbs | 172 Lbs) Mount (Screws): VESA 600 × 400 Mm (4 × M8 × 20L) Pen Tray: 1
|
Software
| - Whiteboarding: EZWrite 5.0
- Wireless Screen Sharing: InstaShare 1
- Account Management: AMS
- Device Management: DMS
- Quick Access Tool: Floating Tool
- Broadcast System: X-Sign Broadcast
|
Warranty
| 03 Years Warranty
|
BenQ RP7502 Interactive Whiteboard In Bangladesh
Designed For Modern Workplaces, BenQ Corporate RP7502 Interactive Display Provide Pioneering Innovations Featuring Cloud Whiteboard, Germ-Resistant Screen, Smart Eye-Care, And Air Quality Sensor For Your Meeting Room. The RP7502 IFP Fosters Collaboration Beyond Locations And Platforms, With The Ease Of Wireless Presentation, Video Conferencing, Open-Platform Software Compatibility, And Hassle-Free Maintenance.
Smooth Real-Time Collaboration
CLOUD WHITEBOARD AND STICKY NOTES FOR MEETING DISCUSSIONS
Packed With User-Friendly Features, BenQ’s EZWrite 5 Software Is The Leading Annotation Solution For Interactive And Collaborative Meetings. Everyone Can Enjoy Enhanced Interactivity By Using EZWrite Cloud Whiteboard To Collect, Categorize, Edit, And Share Notes Between The IFP And Mobile Devices.
Flexible Anytime Annotation
DUAL PENS FOR SIMULTANEOUS COLLABORATION WITH DIFFERENT COLORS
EZWrite 5 Comes With Dual Pens That Allow Two Users To Write Or Draw Simultaneously With Different Colors, Making It Ideal To Inspire Creativity For Brainstorming Discussion.
TAP AND CREATE
Users Can Directly Open EZWrite 5 With A Simple Tap Of The IFP’s NFC Sensor And Immediately Begin Creating Vibrant Notes With Various Colored Pencils, Backgrounds, And Palm Erasers. This Quick And Convenient Access Streamlines Your Discussion Flow For Better Efficiency.
INTELLIGENT HANDWRITING RECOGNITION
Zero Bonded Technology And Fine IR Plus, Ensure The Most Natural Handwriting Experience And Character Recognition Ever. EZWrite’s Handwriting Recognition Feature Will Instantly Convert The Written Text, Numbers, Forms, And Drawings Into Easily Legible Digital Text Without Having To Switch Modes.
FLOATING TOOL
Floating Tool Empowers To Write On Top Of Any App, Video, Website, Document Or Image. It’s Easy To Write, Erase, Record Or Capture Screen At Your Fingertips. It Also Offers A Smooth Writing Experience When Used With HDMI, VGA, And Other Signal Sources, Ensuring Maximum Flexibility.
DUO WINDOWS
This Feature Allows Users To Multitask By Running Two Apps Side By Side On The Interactive Display, Doubling Your Efficiency. Teammates Can Look Up Information On A Browser While Whiteboarding At The Same Time.
Effortless Login With NFC Technology
BenQ's IFPs Support Multi-Account Management Through NFC Technology, Which Allows Users To Directly Access And Manage Their Personal System-Setting, Network Drive And Cloud Storage Space Such As Google Drive, OneDrive And Dropbox. Simply Use Your NFC Card To Tap The Sensor On The Front Of The RP7502 Display For Effortless Log In. You Can Also Scan The QR Code, Or Enter The Username And Password To Log In.
