| BASIC INFORMATION | ||
| BIOS | 128Mb AMI UEFI Legal BIOS with GUI support, - Supports "Plug and Play", - ACPI 5.1 compliance wake up events, - Supports jumperfree, - SMBIOS 2.3 support, - CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V, VDDP, PROM 2.5V, Voltage Multi-adjustment |
|
| Basic Information | ||
| Chipset | AMD X399 | |
| Audio | 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec), - Premium Blu-ray Audio support, - Supports Surge Protection, - Supports Purity Sound™ 4, - Nichicon Fine Gold Series Audio Caps, - 120dB SNR DAC with Differential Amplifier, - TI® NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets), - Pure Power-In, - Direct Drive Technology, - PCB Isolate Shielding, - Impedance Sensing on Front Out port, - Individual PCB Layers for R/L Audio Channel, - Gold Audio Jacks, - 15μ Gold Audio Connector, - Supports DTS Connect |
|
| Memory | ||
| Slots | 4 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE4/PCIE5: single at x16 (PCIE1); dual at x16 (PCIE1) / x16 (PCIE4); triple at x16 (PCIE1) / x8 (PCIE2) / x16 (PCIE4); quad at x16 (PCIE1) / x8 (PCIE2) / x16 (PCIE4) / x8 (PCIE5))*, - 1 x PCI Express 2.0 x1 Slot, - Supports AMD Quad CrossFireX™, 4-Way CrossFireX™, 3-Way CrossFireX™ and CrossFireX™, - Supports NVIDIA® Quad SLI™, 4-Way SLI™, 3-Way SLI™ and SLI™, - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac module (on the rear I/O), - 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE4), *Supports NVMe SSD as boot disks |
|
| Memory | Quad Channel DDR4 Memory Technology, - 8 x DDR4 DIMM Slots, - Supports DDR4 3600+(OC)/3200(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un-buffered memory(U-DIMM), - Max. capacity of system memory: 128GB*, - 15μ Gold Contact in DIMM Slots, *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation. |
|
| Connector & Ports | ||
| LAN | Gigabit LAN 10/100/1000 Mb/s, - 2 x GigaLAN Intel® I211AT, - Supports Wake-On-LAN, - Supports Lightning/ESD Protection, - Supports Dual LAN with Teaming*, - Supports Energy Efficient Ethernet 802.3az, - Supports PXE, *Teaming is supported on Windows® 10 RS2 and above. |
|
| Wireless | - Intel® 802.11ac WiFi Module (Free Bundle), - Supports IEEE 802.11a/b/g/n/ac, - Supports Dual-Band (2.4/5 GHz), - Supports high speed wireless connections up to 433Mbps, - Supports Bluetooth 4.2 / 3.0 + High speed class II |
|
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 03 Years | |
