| BASIC INFORMATION | ||
| Special Feature | Full Gigabit Ports: Up to 10x faster than standard Ethernet, deliver lightning-fast wired performance. Compatct Fiber Tray Design: Store a redundant fiber cable inside and protect the fiber cable from breaking. Easy Setup: Set up your network in minutes with the powerful Aginet app. Remote Management: OMCI (ONT Management and Control Interface) and TR-069 protocols are supported. | |
| Feature | Superfast Dual Band WiFi: Up to 1.2 Gbps WiFi speeds, 300 Mbps on 2.4GHz, 867 Mbps on 5GHz. XPON Dual Modes: Supports GPON and EPON dual modes for flexible fiber internet access. EasyMesh Compatible: Provides whole home WiFi coverage with standard mesh technology. Smooth IPTV: Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming. Enhanced Security: Protect your network with firewalls and the latest WPA3 encryption. | |
| General | Brand: TP-Link Model: TP-Link XC220-G3 Router Type: Wireless & Ethernet |
|
| Basic Information | ||
| Others | Electrical Power: 12V / 1.0A Operating Temperature: 0 - 40 Degree C Storing/Storage Temperature: -40 - 60 Degree C Operating Humidity: 10% - 90% non-condensing Storing/Storage Humidity: 5% - 90% non-condensing Button: WPS/Wi-Fi Button, RESET Button |
|
| Key Features | ||
| Performance | Mesh Technology: Yes MIMO Technology: No |
|
| Features | ||
| Interface | Interface(s): 2 x 10/100/1000 RJ45 LAN, 1 x PON Port Number of WAN Port: No Number of LAN Port: 2 USB Interface: No Internet Connectivity: WAN Only SIM Card Slot Included: No |
|
| Network & Wireless Connectivity | ||
| Security Chip | Operating Frequency: 2.4 GHz, 5 GHz Operation/Working Wireless Modes: Router VPN Support: Yes Voice Assistant: No Built in Antivirus: No |
|
| Connectivity | ||
| Wireless | Antenna (Type & Qty): 2 x External Dual Band Antennas Wi-Fi Generation: Wi-Fi 5 Band: Dual Wi-Fi Coverage (Approximate): 1501-2500 Sq. ft Number of Concurrent User: 16-30 User |
|
| Physical Specifications | ||
| Physical Specs | Hardware Data Transfer Rate (Wifi): 1200 Mbps WiFi Network Standards: IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz LAN Network Standard: 10/100/1000 WAN Network Standard: Not Applicable Data Transfer Rate (Lan): 1000 Mbps |
|
| WARRANTY INFORMATION | ||
| Warranty | 1 Year (Without Adapter) | |
TP-Link XC220-G3
The TP-Link XC220-G3 is an AC1200 Mbps Gigabit Dual-Band Wi-Fi 5 XPON Router designed for high-speed and stable internet connectivity. It's a versatile router suitable for home or small office use, particularly for those who need a balance of wired and wireless connections with XPON support.
1. XPON Technology
XPON Compatibility: Combines GPON and EPON standards, making it compatible with multiple optical network types for seamless integration with different ISPs.
Ideal for FTTH (Fiber to the Home) networks, ensuring reliable and fast data transmission.
2. Dual-Band Wi-Fi
AC1200 Speed: Combines 2.4GHz (up to 300 Mbps) and 5GHz (up to 867 Mbps) bands for a total bandwidth of 1200 Mbps.
Reduced Interference: The 5GHz band is less prone to interference, providing better performance for gaming and streaming.
3. Gigabit Connectivity
Gigabit Ethernet Ports: Features full Gigabit ports (1 WAN and multiple LAN ports) for high-speed wired connections to PCs, smart TVs, and gaming consoles.
4. High-Performance Antennas
External Antennas: Equipped with 4 high-gain antennas to deliver strong and stable Wi-Fi signals throughout your home or office.
Wide Coverage: Suitable for medium-sized spaces with obstacles such as walls.
5. Advanced Features
QoS (Quality of Service): Prioritize bandwidth for specific devices or applications, ensuring optimal performance for activities like streaming or gaming.
MU-MIMO Technology: Allows simultaneous data transmission to multiple devices, reducing latency and improving overall network efficiency.
6. Easy Setup and Management
Web Interface: User-friendly web UI for easy configuration.
Remote Management: Supports remote management via ISP tools, enhancing convenience for troubleshooting and updates.
7. Security
WPA3 Encryption: Provides modern wireless security protocols to protect your network.
Parental Controls: Allows users to manage internet usage for connected devices.
8. Compact Design
A clean, compact design fits easily into home or office spaces without being obtrusive.
Get specific details about this product from customers who own it.
