| Projector Features | ||
| 360-Operation | Yes | |
| 3D Support | Full 3D |
|
| Aspect Ratio | 4:3, 16:9 , LBX, Native, Auto |
|
| Brightness | 4500 ANSI Lumens | |
| Computer Compatibility | WUXGA,1080P,UXGA, SXGA+,SXGA ,WXGA+,WXGA,720P,XGA,SVGA,VGA Compression, VESA standards, PC & Macintosh compatible |
|
| Contrast | 300,000:1 (w/ Extreme black) | |
| Display Technology | DLP | |
| Horizontal Scan Rate | 15.375 – 91.146 KHz |
|
| Keystone Correction | ±30° Vertical, ±30° Horizontal |
|
| Lens Shift | 100% ~116% vertical |
|
| Light Source | Laser phosphor |
|
| Light Source Life | 20,000 hours to 50% brightness (Eco mode) |
|
| Native Resolution | 1080p 1920 x 1080 | |
| Projection Distance | 1.0 ~10 m |
|
| Projection Lens | F/2.5~3.26; f=20.91~32.62mm, 1.6x Manual Zoom |
|
| Projection Method | 360° operation, Portrait mode supported |
|
| Projection Screen Size | 20.2”~320.4” |
|
| Speaker (Watts) | 8W x2 |
|
| Throw Ratio | 1.4 – 2.24 :1 | |
| Vertical Scan Rate | 50 – 85 Hz |
|
| Video Compatibility | 480i/p, 576i/p, 720p/1080i (50/60Hz), 1080p (50/60Hz) |
|
| Zoom Type | 1.6x Manual |
|
| Displayable Colors | 1073.4 million colors (10 bit) |
|
| I/O Interface | HDMI x1, HDMI/MHL x1, VGA in x1, VGA out x1, Audio in 1 x 1, Mic x1, Audio in 2 x1, Audio out x1, USB Power (5V/1.5A), RS232, Video x1, 12V out x1, Micro USB(FW Upgrade), 3D sync |
|
| Noise Level | 32db (Eco mode) | |
| Connectivity | ||
| Power Consumption | Bright : MAX 277W @ 110VAC MAX 269W @ 220VAC Eco: MAX 212W @ 110VAC MAX 206W @ 220VAC Eco Standby : <0.5W Active Standby : <2W |
|
| Power Supply | 100240V, 5060Hz, auto-switching |
|
| Physical Specifications | ||
| Weight | 5 Kg | |
| Dimensions (W x D x H) | 337 x 265 x 108 (excluded adjustment feet) |
|
High lumens brightness projector compatible with 4K & HDR. Optoma DURACORE Technology, IP6X dust resist provides good brightness and reliability. Up to 20,000 hours laser light source life and virtually zero maintenance for system. Amazing color, 90% Rec.709 color gamut coverage to render lifelike images. Big 1.6x zoom & vertical lens shift with smallest size among competition make it labor and time saving for installation. Tilt free orientation, including portrait mode. Focusing on its brightness, the ZH406 is offering best value for the entry professional installation market. This projector is perfect for those applications that simply require the brightness level, ease of installation, with minimum maintenance for up to 20,000 hours. Delivering outstanding reliability, high intensity brightness, compact design, stunning colors and spectacular image quality, The ZH406 is precision engineered to power larger than life experiences.
The ZH406 is the perfect solution for businesses, conference rooms, higher education, auditoriums, exhibitions, digital signage, entertainment venues, projection mapping, and simulation.
The 406 series is capable to accept native 4K signals and compatible with HDR10.
High dynamic range (HDR) technology improves contrast ratio, brightness, and color depth on the display, delivers brighter whites and deeper black levels. It enhances the details and depth of field, making the images clearer and more realistic.
This projector is designed with Optoma’s Airtight Optical Engine with IP6X certification.The airtight enclosure resists dust particles and ensures a long lasting, reliable and maintenance free experience, and ultimate brightness consistency and reliability. The Mercury free laser light source is rated for up to 20,000 hours enabling a low total cost of ownership.
This project achieves 90% Rec. 709 coverage to render lifelike images that will wow your audience.
A large zoom range enables multiple placement possibilities at a variety of distances from the projection screen.
An advantage to this is that expensive interchangeable lens projectors can be substituted with a more cost effective solution whilst still retaining a diverse choice of positioning options.
Simplify installation with lens shift, which provides a wide range of projector placement possibilities.
By individually adjusting each corner of the image, it eliminates any crooked or distorted images in off-angle or restricted space installations for that perfect picture.
The color matching system, combines accurate measurements across multiple projectors creates seamless blends every time.
All ProScene projectors are designed for continuous 24/7 operation. Only industry proven components are used to ensure superior reliability.
Images can be projected over a full 360° range along the vertical axis, including reproduction on a ceiling or floor. This projector can also be placed in portrait mode for applications such as digital signage or for tall thin projection areas.
Versatile System Integration Control Protocols Crestron RoomView, Extron’s IP Link, AMX dynamic device discovery, PJ-Link, Telnet and HTTP protocols are fully supported, allowing the series to be controlled across a network, keeping you in control, wherever you are.
In situations where only absolute darkness is required, this projector can provide a total blackout that functions like mechanical shutter. The change between normal projection to a total black image and vice versa is instantaneous.
This projector features quick start-up and shutdown and reaches full brightness quickly. To maximise energy saving it also includes a ‘pause projection’ feature where the light source can be completely shut off. Unlike conventional lamp based projectors, the laser- light source requires minimal cool-down time.
