NZXT N7 Z590 LGA 1200 10th And 11th Gen WiFi ATX Motherboard (Black)
  • NZXT N7 Z590 LGA 1200 10th And 11th Gen WiFi ATX Motherboard (Black)
  • NZXT N7 Z590 LGA 1200 10th And 11th Gen WiFi ATX Motherboard (Black)

NZXT N7 Z590 LGA 1200 10th And 11th Gen WiFi ATX Motherboard (Black)

Price: 26,850৳
Status: In Stock
Product Code: 6748
Brand: NZXT
Key Features
  • Intel Z590 Chipset
  • LGA1200 Socket
  • 4 x Dual-Channel DDR4 RAM slots
  • Wi-Fi 6E (802.11ax) | Bluetooth 5.2
View More Info

Payment Options

Quantity :

Specification:

BASIC INFORMATION
Supported CPU Intel Socket LGA1200 For 10th And 11th Generation Processors

Intel Core Processors. Please Refer To The CPU Support List.

Turbo Boost Max 3.0 Technology: Supported
Form Factor ATX
Basic Information
Chipset Intel: Z590
Audio Realtek: ALC1220 Codec

Channel: 8-Channel High Definition Audio

Playback: 32-Bit / 192kHz DAC

Capacitors: Nichicon Fine Gold Series
Memory
Slots 1 X PCIe 4.0 X16 (X16 Mode)

1 X PCIe 3.0 X16 (X4 Mode)

3 X PCIe 3.0 X1
Memory Memory Slots: 4 X 288-Pin

Memory Support: DDR4 2133, 2400, 2666, 2800, 2933, 3200, 4400, 4600 MHz

Maximum Capacity: 128 GB

Channel Architecture: Dual Channel

ECC Support: Non-ECC Unbuffered
Graphics
Graphics Intel Xe Graphics (11th Gen CPUs) / UHD (10th Gen CPUs)

HDMI 2.0 / HDMI 1.4b

HDMI Max Resolution: 4096x2160@60Hz
Connector & Ports
HDMI HDMI 2.0 / HDMI 1.4b
LAN Realtek: RTL8125BG 2.5G
Supported Storage SATA: 4 X SATA III

M.2: 1 X 2242, 2260, 2280 (PCIe 3.0 X4, SATA (Unspecified)) U.2 None

Optane Memory Support: Yes

RAID Support: RAID 0, 1, 5, 10
Internal I/O Ports 1 X USB 3.1 / USB 3.2 Gen 1 Header (Supports 1 USB Type-C Port)

2 X USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)

3 X USB 2.0 Header (Supports 6 USB Type-A Port)

Multi-GPU Support 2-Way AMD CrossFireX

Air Cooling 1 X 4-Pin CPU

5 X 4-Pin System

Liquid Cooling 1 X 4-Pin Pump

Power Connectors 1 X 24-Pin Mainboard

1 X 8-Pin ATX

1 X 4-Pin ATX

LED Header 2 X RGB

Diagnostics Power, Reset
WiFi Intel Dual-Band Wireless: AX210 Wi-Fi 6E

Protocol: 802.11 A/B/G/N/Ac/Ax

Frequency Bands: 2.4 / 5 / 6 GHz

MU-MIMO Support: Supported

Bluetooth: V5.2
WARRANTY INFORMATION
Warranty 3 Years

Description :

NZXT N7 Z590 LGA 1200 10th And 11th Gen WiFi ATX Motherboard (Black)

NZXT N7 Z590 ATX Motherboard Built On The Z590 Chipset, You Can Access An LGA1200 Socket, Four Dual-Channel DDR4 RAM Slots, Six SATA III Ports, And Two M.2 Interfaces. Equip Your Rig With An Array Of Graphics And Utility Cards With One PCIe 4.0 X16, One PCIe 3.0 X16 (In X4 Mode), And Three PCIe 3.0 X1 Slots. Connect Various Resource-Demanding Peripherals Such As Cameras And External Drives With USB 3.2 Gen 1 And Gen 2 Type-A Ports. A Single USB 3.2 Gen 2x2 Port Offers Up To 20 Gb/S Data Transfer Speeds, Suitable For Workstation Hubs, Audio Interfaces, And More High-Powered Devices. You Can Use Bluetooth 5.2 Technology To Leverage Wireless Devices Such As Controllers And Speakers. Wi-Fi 6E (802.11ax) Technology Enables You To Connect To Your Wireless Network Easily Or Use The RJ45 LAN Port If You Prefer A Hard-Wired Connection.


Features:

  • The N7 Z590 Uses A 12+2 DrMOS Power Phase Design To Balance Electrical Current And Deliver Efficient Power To Your Installed Components.
  • Fan And RGB Lighting Can Be Adjusted With The Included NZXT CAM Software, Allowing You To Fine-Tune Your Fans In Performance And Style.
  • Integrated I/O Shield Provides An Efficient Layout For Connectors And Makes Installation Quick And Easy.
  • Intel Optane Memory Support Allows You To Use Optional Intel M.2 Drives To Boost The Performance Of Hard-Disk Campaigns Within Your System, Giving You SSD-Like Performance.
  • Multi-GPU Support With AMD CrossFireX Allows You To Equip Your Rig With Two Graphics Cards To Enhance Visual Fidelity.
  • The N7 Z590 Supports Memory Overclocking Up To 4266 MHz And Intel XMP 2.0, Ensuring You Get The Most Out Of Your Memory.
  • Immerse Yourself Deep Into Your Media With 8-Channel High-Definition Audio, Delivering Clean Sound Whether You Are Playing Games Or Enjoying Streaming Media
