| Key Feature | ||
| Certification | 80 PLUS PLATINUM | |
| Efficiency (Approx.) | 94% Typically | |
| Fan Size | 135mm | |
| Frequency | 50Hz – 60Hz | |
| Modular Type | Full Modular | |
| Output | ||
| Voltage | 100VAC – 240VAC ~ ±10% (Active PFC) | |
| Power | 1000w | |
| Connectors | ||
| Connector | Main Power 1 X 20+4 pin CPU 1 X 8 Pin EPS 12V PCI-E 6 X 6+2 SATA 9 Molex 6 Floppy 1 | |
| Input | ||
| Current | 13A – 6.5A | |
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 7 Years | |
>80 PLUS PLATINUM certified - Up to 94% efficient, to reduce your electricity bill
>1000W Continuous Power - Guaranteed 1000W of Continuous Power from Antec
>Save Energy and Money - Reduce your electricity bill by up to 25%
>AQ7 - Antec Quality 7 year warranty and lifetime global 24/7 support
>16-pin Socket - Industry-leading 16-pin sockets double the modular connectivity by supporting 2 different 8-pin cables per socket and allow for future connector changes
>28(20+8)-pin MBU socket - World's first socket for possible future MBU connectors
>135 mm DBB Silence - Whisper-quiet high-quality double ball bearing fan with a long lifetime
>Thermal Manager - An advanced low voltage fan control for optimal heat & noise management
>High Current Rails - 4 High Current +12V rails with high load capabilities ensure maximum CPU & GPU compatibility
>100% +12V - Output for maximum CPU & GPU support
>Multi PCI-E - 6 PCI-E connectors for multiple GPU support
>CircuitShield - Full suite of industrial-grade protections: Over Current Protection (OCP), Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Surge & Inrush Protection (SIP), No Load Operation (NLO) & Brown-Out Protection (BOP)
Continuous power of 1000W delivers safe, reliable output for high-performing computer systems. Four fully-protected, high current +12v rails ensure high-end CPU and graphics cards compatibility. The High Current Pro Platinum series provides ultra-high power efficiency of at least 89% (up to 94% under real-world operating environments for this model) at any load between 20% and 100%, saving your money on your electric bill, reducing heat in your computer's system, and prolonging its life. All Japanese Heavy-Duty Caps - All high-performance Japanese capacitors ensure the tightest DC stability and regulation
