Aigo Gp550 550w Power Supply Specifications:
- Power Supply Size: 160mm * 150mm * 85mm
- Power Standard: Atx 12v
- Applicable To Cpu Range: Amd, Intel
- Pfc Type: Active Pfc
- Rated Power: 550w
- Maximum Power: 550w
- Efficiency: 80%
- Input Voltage: 160v-264v
- 3.3v Output Current 20a + 5v Output Current 15a + 12v1 Output Current 48a – 12v Output Current 0.3a + 5vsb Output Current 2.5a
- Support Wide Voltage: Yes
- Support Temperature Control Pwm: Yes
- Certification: Cb, Ccc, Fcc, Class, B, Ce, Rohs
- Product Weight: 1900g
- Support Power: 20p / 24p Motherboard
- Power Output Design: Multiplex + 12v
- Ide Interface: 2
- Sata Interface: 4
- Cpu Interface: P4 + 4 19: Video Card Interface: (6pin + 2)* 2
|
**03 Years Warranty
|
Aigo Gp550 550w POWER SUPPLY
The Aigo Gp550 550w POWER SUPPLY Rated Power 550 Watts, Suitable For High-End Computer Configuration Comply With Intel Atx12v Specification Design, Support Intel, Amd Full Range Of Dual-Core Platform,Energy Efficient Silent Fan.Built-In Pfc, Dual Magnetic Ring Magnetic Amplifier Circuit, Aigo Gp550 550w POWER SUPPLY High Frequency Low Resistance Filter Capacitor, Ensure That The Current Is Pure And Stable. 12cm Hydraulic Bearing Fan, Quiet And Durable, Large Air Volume.Intelligent Temperature Control Circuit Design, Automatically Adjust Fan Speed, Extend Service Life.Large Speaker Capacity, Large Capacity, Support For Wide Use, Can Still Be Used Under Unstable Voltage Environment General.Multi-Function Protection Circuit Design, With Over Voltage, Over Current, Overload, Under Voltage, Short Circuit, Light Protection 9: Innovative Pest Control Technology Design.
