Load Capacity

Overload capability

 110% only audible

 warning, 110-130%

for 30 sec, >130%

for 100 ms

Input Voltage

Nominal voltage 208Vac/220Vac/

230Vac/240Vac
Input voltage range

160Vac-300Vac from 50% to 100% load, 110Vac-

300Vac up to 50% load

Output Voltage

Nominal voltage 208Vac/220Vac/230

Vac/240Vac
Static voltage Regulation

at %100 ±2% linear load (On-Line and battery mode)
Voltage THD at rated

linear load <3% (linear load), <6% (non-linear

Frequency (Battery Mode)

50/60 Hz

Noise Level

< 45 dBA to 1 m

Battery

12V 2*9Ah, Lead-acid, sealed

Rectifier Type

Yes

Frequency

Nominal frequency

 50/60 Hz (selectable)
Input frequency range

(On-Line mode) ±7%

Power Factor

0,99

Voltage Range

Nominal voltage 208Vac/220Vac/

230Vac/240Vac
Input voltage range 160Vac-300Vac from 50% to 100% load, 110Vac-300Vac up to 50% load

Backup Time

15 min

Voltage Range

Nominal voltage 208Vac/220Vac/

230Vac/240Vac
Static voltage Regulation at %100 ±2% linear load (On-Line and battery mode)
Voltage THD at rated linear load <3% (linear load), <6% (non-linear load)

Power Factor

0,9

Transfer Time

0 ms (On-Line)

Warranty

02 Years Warranty
