GIGABYTE B450 AORUS PRO WIFI AM4 ATX MOTHERBOARD

GIGABYTE B450 AORUS PRO WIFI AM4 ATX MOTHERBOARD

Price: Out Of Stock
Status: Out Of Stock
Product Code: 1354
Brand: Gigabyte
Key Features
  • Supports Up to AMD Ryzen 5000 series Processors
  • Chipset: AMD B450
  • Memory: 4 x DDR4, Max 64 GB
  • 4 x PCI Express slots
View More Info

Payment Options

Quantity :
  • Specification
  • Description
  • Reviews ( 0)

Specification:

BASIC INFORMATION
BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a,
DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor ATX Form Factor; 30.5cm x 24.4cm
Basic Information
Chipset AMD B450
Audio Realtek® ALC1220-VB codec High Definition Audio 2/4/5.1/7.1-channel Support for
S/PDIF Out
CPU AMD Ryzen™ 2nd Generation processors AMD Ryzen™ with Radeon™ Vega Graphics
processors AMD Ryzen™ 1st Generation processors
Memory
Slots 4 x DDR4 DIMM
Memory Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules Support
for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC
mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory
modules Support for Extreme Memory Profile (XMP) memory modules
Maximum Mamory: 64 GB
Storage 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0
x4/x2 SSD support) (M2A_SOCKET) 1 x M.2 connector (Socket 3, M key, type
2242/2260/2280 PCIe 3.0 x2 SSD support)(M2B_SOCKET) 6 x SATA 6Gb/s
connectors Support for RAID 0, RAID 1, and RAID 10
Connector & Ports
LAN Intel® GbE LAN chip (10/100/1000 Mbit)
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x M.2
Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 1 x
water cooling CPU fan header 2 x system fan headers 1 x system fan/water
cooling pump header 1 x CPU cooler LED strip/RGB LED strip header 2 x
digital LED strip headers 2 x digital LED strip power select jumpers 1 x RGB
(RGBW) LED strip header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x
Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module
only) 1 x Clear CMOS jumper
USB Port Chipset: 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support 1 x
USB 3.1 Gen 2 Type-A port (red) on the back panel 2 x USB 3.1 Gen 1 ports
available through the internal USB header 4 x USB 2.0/1.1 ports available
through the internal USB headers CPU: 4 x USB 3.1 Gen 1 ports on the back panel
WARRANTY INFORMATION
Warranty 03 years

Description :

GIGABYTE B450 AORUS PRO WIFI

The AORUS Core is inspired by the falcon's aggressive nature and hunting prowess. The falcon uses its razor sharp talons to swiftly strike down its prey with exceptional efficiency and precision, qualities that are exemplified in the fine details of AORUS design.

  • Supports AMD 2nd Generation Ryzen™/ Ryzen™ with Radeon™ Vega Graphics/ 1st Generation Ryzen™ Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Intel® Dual Band 802.11ac WIFI & BT 4.2
  • HDMI, DVI-D Ports for Multiple Display
  • Integrated I/O Shield of Ultra Durable™ Design
  • Dual Ultra-Fast NVMe PCIe Gen3 M.2 (x4, x2) with Dual Thermal Guards
  • ALC1220-VB Enhanced 114dB(Rear) / 110dB(Front) SNR in Microphone with WIMA Audio Capacitors
  • RGB FUSION with Multi-Zone LED Light Show Design, Supports Digital LED & RGB LED Strips
  • Intel® GbE LAN with cFosSpeed Internet Accelerator Software
  • Smart Fan 5 Features 6 Temperature Sensors and 5 Hybrid Fan Headers with FAN STOP
  • APP Center Including EasyTune™ and Cloud Station™ Utilities
  • CEC 2019 Ready, Save Power with a Simple Click
