| Video Memory Specifications | ||
| Memory Size | 8GB | |
| Memory Type | GDDR5 |
|
| Resolution | DisplayPort: 5120×2880@60Hz HDMI: 4096×2160@60Hz DVI:2560x1600@60Hz |
|
| Core Clock | 2048 | |
| Memory Bus (Bit) | 256-bit |
|
| INTERFACE | PCI-Express 3.0 |
|
| Memory Clock | 1750 MHz, 7000 MHz Effective |
|
| Stream Processors | 2048 Stream Processors |
|
| Interface | ||
| Display Port | 2x DisplayPort 1.4 | |
| HDMI | 2x HDMI | |
| Power Specifications | ||
| Power Consumption | 180W | |
| Power Connector (Pin) | 1 x 8-pin AUX Power Connector |
|
| Recommended Power Supply | 500 Watt or greater power supply |
|
| Display Option | ||
| Multi Display | Yes ( Maximum 5 Outputs ) |
|
| General | ||
| Graphics Chipset | RX 570 8G GDDR5 | |
| DVI | 1x DVI-D | |
| Application Programming Interfaces | ||
| OpenGL | 4.5 | |
| DirectX | 12 | |
| Physical Specifications | ||
| Dimensions | 230(L)X 125(W)X 40 (H) mm |
|
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 2 Years Warranty |
|
