| Basic Information | ||
| Others | Material: Steel/brushed aluminum housing Form Factor: SFX PFC: Active PFC (PF)>0.90 at full load Protective Circuit: OCP/ OPP/ UVP/ OVP/ OTP/ SCP | |
| Basic Information | ||
| CPU | 1 x 8/4+4 Pin CPU/ATX 12V connector (600mm) x2pcs | |
| Key Feature | ||
| Certification | 80 PLUS Gold | |
| Efficiency (Approx.) | 91.89% Max | |
| Fan Size | 850W Fan RPM: 1000-2800 RPM Noise Level: 17.1-43.1 DBA Bearing Type: 31.Fluid Dynamic Bearing (FDB) | |
| Modular Type | Fully modular | |
| Molex | 4 x 4-Pin Peripheral connector (120mm-120mm-120mm-120mm) x 1pcs | |
| Output | ||
| Total Power | 750W | |
| DC Output | 750W | |
| Connectors | ||
| Main Power | 1 x 24 / 20-Pin motherboard connector (300mm) x 1pcs | |
| PCI-E | 1 x 8/6+2 Pin PCle connector (400mm) x1pcs 2 x 8/6+2 Pin PCle connector (400mm-120mm) x1pcs | |
| SATA | 4 x SATA connector (120mm120mm-120mm-120mm) x 2pcs | |
| Input | ||
| Frequency Range | 50Hz – 60 Hz | |
| Voltage | 100 – 240 Vrms | |
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 5 years | |
The Lian Li SP850 850W Fully Modular Power Supply combines looks with high-performance functionality, making it a perfect choice for small-form-factor PCs with power-hungry components. The elegant and timeless design's brushed metal housing lends a touch of sophistication to your system. The SP850 has earned the 80 PLUS GOLD Efficiency certification and delivers an incredible 91.55% efficiency at 115V and 50% load. This level of efficiency decreases power waste, bringing it closer to the 80PLUS PLATINUM standard of 92% efficiency under the same conditions. The Lian Li SP850 stands out for its completely modular construction and braided cables. This not only keeps the inside of your PC clean and nice, but it also allows for easy customization and cable management. The great durability of Japanese electrolytic capacitors improves the reliability and lifetime of the power supply. The SP850 offers a ZERO RPM mode that functions when the load is less than 40% for individuals who desire quiet operation. This function ensures that the power supply remains silent under low-demand scenarios. OVP (Over Voltage Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), and OTP (Over Temperature Protection) are all available on the Lian Li SP850. These measures protect both the power source and the connected components from potential hazards. The addition of a 12VHPWR connector cable compatible with 40 series graphic cards enhances the versatility of the PSU, allowing it to meet the needs of modern graphics cards. The Lian Li SP850 is a durable and visually appealing power supply unit that not only meets the power needs of high-performance systems but also adds a touch of class to the overall design. The SP850 blends efficiency, durability, and elegance in a tiny package, making it ideal for PC geeks and gamers alike.
