| BASIC INFORMATION | ||
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold, and Celeron Processors Processor socket LGA1700 |
|
| Form Factor | ATX 243.84mmx304.8mm |
|
| Basic Information | ||
| Chipset | INTEL Z790 | |
| Audio | Realtek ALC4080 Codec 7.1-Channel USB High-Performance Audio Supports S/PDIF output |
|
| Expansion Slots | ||
| PCI | 3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 PCIe 3.0 supports up to x1 (From Chipset) |
|
| M.2 Socket | 4x M.2 slots | |
| MEMORY SPECIFICATIONS | ||
| Type | DDR5 | |
| Memory | ||
| Slots | 4 x DIMM | |
| Supported Memory | 4x DDR4, Maximum Memory Capacity 128GB Max. overclocking frequency: 1DPC 1R Max speed up to 7200+ MHz 1DPC 2R Max speed up to 6600+ MHz 2DPC 1R Max speed up to 6400+ MHz 2DPC 2R Max speed up to 5600+ MHz Supports Intel XMP3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
|
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | 1x HDMI 1x DisplayPort Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI 2.1 | |
| Display Port | 1x DisplayPort 1.4 | |
| USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
|
| LAN | Intel 2.5Gbps LAN | |
| Supported Storage | 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280/2260/2242 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 6x SATA 6G port |
|
| Others | ||
| Special Features | LED FEATURE: 4x EZ Debug LED | |
| WARRANTY INFORMATION | ||
| Warranty | 3 years | |
The MSI PRO Z790-A WIFI DDR5 Intel 12th and 13th Gen ATX Motherboard is a high-performance motherboard designed to support the latest generation of Intel Core processors, including the 12th and 13th Gen Intel Core processors, Pentium Gold, and Celeron Processors. With its advanced features and robust design, it provides an excellent foundation for building a powerful and reliable PC system.One of the standout features of this motherboard is its support for DDR5 memory, which offers higher bandwidth and improved performance compared to previous memory standards. With four DIMM slots and a maximum memory capacity of 128GB, the motherboard provides ample room for high-speed memory configurations. It also supports Intel XMP 3.0 overclocking and Dual-Controller Dual-Channel mode, allowing users to push the memory to its limits and achieve exceptional performance.
The MSI PRO Z790-A WIFI motherboard is designed with an ATX form factor, providing compatibility with a wide range of PC cases. It includes several external I/O ports for easy connectivity and supports various cooling options with multiple fan connectors. The motherboard also incorporates LED features, including four EZ Debug LEDs, enhancing the visual appeal of the system.MSI offers a three-year warranty for the PRO Z790-A WIFI motherboard, ensuring peace of mind and support for the product.
