| Key Feature | ||
| Certification | 80 PLUS Bronze | |
| Efficiency (Approx.) | 85%Typically | |
| Fan Size | 120mm |
|
| Frequency | 50-60Hz | |
| MTBF | >100,000 Hours | |
| Output | ||
| Voltage | 100-240Vac | |
| Power | 550W | |
| Connectors | ||
| Connector | MB 20+4 PIN CONNECTORS: 1 CPU 12V 4+4 PIN CONNECTORS: 1 SATA CONNECTORS: 6 PERIPHERAL 4-PIN CONNECTORS: 2 FDD CABLE 4-PIN CONNECTORS: 1 PCI-E 6+2 PIN CONNECTORS: 2 |
|
| Input | ||
| Current | 8-4A | |
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 5 Years | |
●︎ ATX VERSION: ATX 12V v2.4
●︎ PFC: Active PFC
●︎ OPERATION VOLTAGE: 100-240Vac
●︎ INPUT VOLTAGE: 100-240Vac
●︎ INPUT CURRENT: 8-4A
●︎ INPUT FREQUENCY: 50-60Hz
●︎ DIMENSIONS (L X W X H): 140 x 150 x 86 mm
●︎ FAN SIZE: 120mm
●︎ FAN BEARING: LDB
●︎ POWER GOOD SIGNAL: 100-500ms
●︎ HOLD UP TIME: 16ms at 80% load
●︎ EFFICIENCY: 85% @ Typical Load
●︎ ERP 2013 LOT 6: Yes
●︎ MTBF: >100,000 Hours
●︎ OPERATING TEMPERATURE: 0-40°C
●︎ PROTECTIONS: OPP, OVP, UVP, OCP, OTP, SCP
●︎ REGULATORY: CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
●︎ MB 20+4 PIN CONNECTORS: 1
●︎ CPU 12V 4+4 PIN CONNECTORS: 1
●︎ SATA CONNECTORS: 6
●︎ PERIPHERAL 4-PIN CONNECTORS: 2
●︎ FDD CABLE 4-PIN CONNECTORS: 1
●︎ PCI-E 6+2 PIN CONNECTORS: 2
●︎ 80 PLUS: Bronze
●︎ WATTAGE: 500 to 750W
●︎ SERIE: MasterWatt Series
**5 years warranty
