| Key Feature | ||
| Certification | 80 PLUS Standard 230V EU | |
| Efficiency (Approx.) | 85% @ Typical Load | |
| Fan Size | 120mm | |
| Frequency | 50-60Hz | |
| Output | ||
| Voltage | 200-240Vac | |
| Power | 400W | |
| Connectors | ||
| Connector | MB 24-PIN CONNECTORS x1 EPS 4+4 PIN CONNECTORS x1 PCI-E 6+2 PIN CONNECTORS x1 SATA CONNECTORS x3 PERIPHERAL 4-PIN CONNECTORS x2 |
|
| Input | ||
| Current | 4A | |
| Others | ||
| Others | HOLD UP TIME: >14ms at 100% load MTBF: >100,000 Hours |
|
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 3 Years | |
POWER UP
The Elite - v4 series power supply unit is a dependable choice for entry level PC builders and office work systems. The quiet 120mm fan, 80 PLUS White EU 230V efficiency, and 3 year warranty deliver a PSU that provides function and resilience you can count on. It's the perfect option for work horse systems stored and operated in less than ideal conditions and climates. This PSU has been engineered for reliability with a focus on reducing random shutdowns in conditions where power sources are inconsistent and unstable, making it ideal for locations prone to experience brown outs. The Elite - v4 is a complete solution, offering performance and stability at an affordable price.
ACTIVE PFC + FORWARD TOPOLOGY DESIGN
A power supply unit works by taking power directly from the wall or other fixed power source, converting it to the correct output required by the connected components, and then distributing that power to said components. If any part of this process is interrupted or executed poorly, the connected system components and the PSU itself could be damaged. Active PFC uses a circuit to correct power factor leading to reduced total harmonics, corrected AC input voltage, and increased overall efficiency output.
HIGH TEMPERATURE RESISTANCE
The new Elite - v4 has a maximum operating temperature of 40°C. That's at the level of many 80 Plus certified power supply units on the market today. This higher operating temperature allows you to power your system safely in warmer environments without having to worry about your system overheating or shutting off unexpectedly. The higher heat resistance also reduces temperature based wear, increasing the lifespan of the unit by a noticeable amount.
PEAK POWER TOLERANCE
This power supply unit can push out an additional 50W above maximum load for up to 10 seconds before turning off. This will allow your system a chance to save data and complete current processes in the event of output surge or overloading. While it may not be a feature you'll actively need all the time, it can be extremely useful in an emergency scenario.
