| Audio | ROG SupremeFX8-Channel High Definition Audio CODEC S1220A
- Dual OP Amplifiers,
- Impedance sense for front and rear headphone outputs,
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking,
- High quality120dBSNR stereo playback outputand113dBSNR recording input,
- Supports up to 32-Bit/192kHz playback *,
Audio Feature :
- SupremeFX Shielding Technology,
- Gold-plated jacks,
- Optical S/PDIF in port(s) at back panel,
- Audio Shielding,
- Premium Japanese audio capacitors,
- Audio Cover,
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio. |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Chipset | AMD B550 |
| CPU | AMD AM4 Socket for AMD Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors |
| Form Factor | ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| Graphics | Integrated Graphics Processor,
Supports AMD 2-Way CrossFireX Technology |
| HDMI | 1 x HDMI 2.1([email protected]) |
| Internal I/O Ports | 1 x CPU Fan connector(s),
1 x CPU OPT Fan connector(s),
3 x Chassis Fan connector(s),
1 x AIO_PUMP connector,
1 x AAFP connector,
2 x Aura RGB Strip Header(s),
1 x Addressable Gen 2 header(s),
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s),
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),
1 x M.2 Socket 1 with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode),
1 x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode),
6 x SATA 6Gb/s connector(s),
1 x Thunderbolt header(s),
1 x 24-pin EATX Power connector(s),
1 x 8-pin ATX 12V Power connector(s),
1 x 4-pin ATX 12V Power connector(s),
1 x System panel(s),
1 x Thermal sensor connector(s),
1 x Clear CMOS jumper(s) |
| LAN | Intel I225-V 2.5Gb Ethernet
ASUS LANGuard |
| Memory | Type:
Dual Channel Memory Architecture,
OptiMem II
Slots:
4 x DIMM slots
Supported Memory:
4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory,
4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory,
ECC Memory (ECC mode) support varies by CPU,
Maximum Memory:
128GB, DDR4 |
| Storage | 1 x M.2_1 socket 3, with M key, type 2242/2260/ 2280/ 22110 storage devices support(SATA & PCIe 4.0 x4 mode),
AMD B550 Chipset :
Support Raid 0, 1, 10
Total supports 2 x M.2 slot(s) and 6 x SATA 6Gb/s ports,
1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*,
1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode),
6 x SATA 6Gb/s port(s) |
| USB Port | Rear USB Port ( Total 8 ),
2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®),
4 x USB 3.2 Gen 1 port(s)(4 x Type-A),
2 x USB 2.0 port(s),
Front USB Port ( Total 6 ),
2 x USB 3.2 Gen 1 port(s),
4 x USB 2.0 port(s) |
