| BASIC INFORMATION | ||
| BIOS | 128Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 6.0 Compliant wake up events, SMBIOS 2.7 Support, CPU Core/Cache, GT, DRAM, PCH +1.0V, VCCST Voltage Multi-adjustment |
|
| Form Factor | Micro ATX Form Factor: 7.76-in x 7.4-in, 19.7 cm x 18.8 cm, Solid Capacitor design |
|
| Basic Information | ||
| Chipset | Intel H410 | |
| Audio | 7.1 CH HD Audio (Realtek ALC887 Audio Codec) - Supports Surge Protection |
|
| CPU | Supports 10th Gen Intel® Core™ Processors (Socket 1200), Digi Power design, 5 Power Phase design, Supports Intel Turbo Boost Max 3.0 Technology |
|
| Memory | ||
| Memory | Type: DDR4, Slots: 1 x PCI Express 3.0 x 16 Slot, 1 x PCI Express 3.0 x 1 Slot, Supported Memory: - Dual Channel DDR4 Memory Technology, - 2 x DDR4 DIMM Slots, - Supports DDR4 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory, - Supports Intel Extreme Memory Profile (XMP) 2.0, - 15μ Gold Contact in DIMM Slots, Maximum Memory: Max. capacity of system memory: 64GB |
|
| Storage | 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug | |
| Graphics | ||
| Graphics | -Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1, -Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz, -Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. -VP9 10bit and VC-1 are for decode only. VP8 and VP9 encode are not supported by Windows OS, -Supports up to 2 displays simultaneously |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI 1.4 | |
| LAN | 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) | |
| Internal I/O Ports | 1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 4 x USB 2.0 Ports (Supports ESD Protection), 2 x USB 3.2 Gen1 Ports (Supports ESD Protection), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jacks: Line in / Front Speaker / Microphone |
|
| USB Port | 1 x USB 2.0, 1 x USB 3.2 Gen1 |
|
| WARRANTY INFORMATION | ||
| Manufacturing Warranty | 03 Years Warranty | |
5 Power Phase Design
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers enhanced performance with the lowest temperature for advanced gamers.
Premium 50A Power Choke
Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.
Clever Access Memory
Conventional PC systems processor can only access a fraction of graphics memory and limits system performance. With Clever Access Memory, the data channel gets expanded to harness the full potential of GPU memory, removes the bottleneck and increase performance.
3 Graphics Outputs
Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution.
Water Pump Header
This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 2A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
Live Update & APP Shop
ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.
