| Case Features | ||
| Case Type | Mid Tower | |
| Drive Bays | 5.25": 1 3.5" /2.5": 3/2 2.5": 3 |
|
| Expansion Slots | 7 | |
| Fan Support | Front : 3 x 120mm/2 x 140mm Top: 3 x 120mm / 2 x 140mm (w/o ODD and w/o ODD bracket) 2 x 120mm / 2 x 140mm (w/o ODD but with ODD bracket) 2 x 120mm / 1 x 140mm(When ODD is installed) Power Supply Shroud: 2 x 120mm Rear: 1 x 120mm |
|
| I/O Port | Power, LED Control Button, 2 x USB3.0, HD-AUDIO | |
| Motherboard Support | ATX, M-ATX, ITX | |
| Others | Maximum CPU Cooler Height: ≤ 175mm Maximum Graphics Card Length: ≤ 405mm |
|
| Pre- Installed Fans | 3 x 120mm ARGB fans in front 1 x 120mm fan (Reverse Fan) on PSU shroud & 1 x 120mm fan in rear |
|
| PSU | ≤ 205mm | |
| Radiator Support | Front: 120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel) (≤ 30mm thickness when fans are installed inside of front panel) [Max Radiator Length ≤ 405mm] Top: 240/280/360mm (w/o ODD and w/o ODD bracket) 240/280mm (w/o ODD but with ODD bracket) 120mm(When ODD is installed) Rear: 120mm [Max Radiator Length ≤ 405mm] |
|
| Tempered Glass Panel | Yes | |
| Physical Specification | ||
| Dimensions | 463 x 220 x 486 mm | |
| Weight | 7.55KG | |
| Physical Specifications | ||
| Color | Black | |
The DP502 FLUX mid-tower gaming case is well equipped with an industry-leading design of advanced ventilation, taking the Antec Dark league gaming cases to the next generation. When Intel and AMD announced their latest CPUs, they all deliver remarkable performance upgrades and better productivity, it also means the functional requirement of PC equipment needs to be taken to the next level, especially the thermal performance. To cope with the stress of enhanced heat dissipation, Antec developed a revolutionary structure for airflow, providing an improved and powerful cooling solution for your system. What is the F-LUX Platform? The definition of FLUX is Flow Luxury. The F-LUX Platform is a new industry-leading and highly efficient design by Antec featuring an advanced case structure for excellent airflow and 5 x 120 mm fans included. A core element of the design ethos was to enhance GPU cooling performance. You only need the LED mode button to control all the addressable LEDs.
